MS Flat Bar Supplier & Stockist in Raipur
MS Flats are flat mild steel sections widely used for fabrication, engineering, machinery, manufacturing and industrial applications. Raipur Steel Mart supplies MS Flats based on required size, quantity and application.
Steel Trading • Stockist • Supply
Serving Raipur, Raigarh, Jalna, Nagpur and Mumbai.
Why Choose MS Flats?
Rolled to width
Arrives at the width you ordered with rolled edges, so there is no cutting a strip from plate before work starts.
Weight is w × t × 0.00785
Width and thickness in millimetres times 0.00785 gives kilograms per metre — a 50 × 6 flat is about 2.36 kg/m.
Bends, drills and welds
Easy to bend cold, punch, drill and weld, which is why it is the default for cleats, straps and brackets.
Cleats, straps and frames
Cleats and gussets, base and packing straps, gate and grille frames, ties, stiffeners, brackets and hold-down straps.
What an MS flat is, and how it differs from plate
An MS flat is a rectangular bar — wider than it is thick, and rolled to a set width rather than cut from a larger sheet. That is the real difference from plate: a flat arrives already at the width you asked for, with rolled edges, so it goes straight into fabrication without cutting a strip first.
Weight is width times thickness times 0.00785, in millimetres, giving kilograms per metre. A 50 × 6 mm flat is 50 × 6 × 0.00785, about 2.36 kg per metre. Share the widths and thicknesses you need and we will confirm what can be arranged.
MS Flat Specifications
MS Flats are supplied on a requirement basis. Share the details below with your enquiry and we will confirm what can be arranged against current availability.
| Detail | Requirement |
|---|---|
| Product | MS Flat |
| Section | Flat |
| Size | As per requirement |
| Grade | As per requirement |
| Quantity | As required |
| Brand | Subject to availability |
What to Specify When Buying MS Flats
Four details that keep an MS Flat enquiry moving.
- 01 — Size — Mention the required width and thickness.
- 02 — Grade / Specification — Mention the required grade or specification where applicable.
- 03 — Quantity — Provide the required quantity.
- 04 — Delivery Location — Share the delivery location for quotation and supply planning.
Share your required size, grade, quantity and delivery location with our team to confirm current availability.
Applications of MS Flats
Engineering & Fabrication
Used in general engineering and fabrication requirements.
Machinery & Components
Used for manufacturing and fabrication of various machine components.
Grills, Gates & Railings
Used in grills, gates, railings and similar fabricated work.
Structural & Support Work
Used in supports, frames and fabricated structures where applicable.
Industrial Applications
Used across different industrial and manufacturing requirements.
Repair & Maintenance
Used for maintenance, replacement and general fabrication requirements.
Why Source MS Flats from Raipur Steel Mart?
A steel trading, stockist and supply company serving Raipur, Raigarh, Jalna, Nagpur and Mumbai.
Product & Requirement Support
Send the size, grade and application you need and we help you shortlist what fits. The requirement is agreed before quoting, not after.
Quality-Conscious Sourcing
Material is selected against the specification and the intended application. What reaches your site matches what was agreed in the order.
Bulk Requirement Support
Project, commercial and repeat requirements are supported. Dispatch can be phased around your requirement rather than delivered in one go.
Responsive B2B Service
One point of contact from enquiry through quotation and dispatch. Straightforward answers on availability and timelines.
MS Flat Weight Chart
Kilograms per metre, with w and t in millimetres
Flats are quoted and dispatched by weight, while drawings and cutting lists are prepared in running length. The industry converts between the two using a single approximation derived from the density of steel and the cross-section of a flat. A 50 × 6 mm flat works out to 50 × 6 × 0.00785 ≈ 2.355 kg per metre, so a 12 metre length weighs roughly 28.26 kg.
A general calculation reference only. Figures are approximate and this is not a statement of available sizes — share your required width and thickness and we will confirm what can be arranged.
| Size (w × t) | Approx. kg/m | 6 m Weight |
|---|---|---|
| 25 × 3 mm | 0.589 kg | 3.53 kg |
| 25 × 5 mm | 0.981 kg | 5.89 kg |
| 25 × 6 mm | 1.177 kg | 7.06 kg |
| 32 × 6 mm | 1.507 kg | 9.04 kg |
| 40 × 5 mm | 1.570 kg | 9.42 kg |
| 40 × 6 mm | 1.884 kg | 11.30 kg |
| 50 × 6 mm | 2.355 kg | 14.13 kg |
| 50 × 8 mm | 3.140 kg | 18.84 kg |
| 50 × 10 mm | 3.925 kg | 23.55 kg |
| 65 × 8 mm | 4.082 kg | 24.49 kg |
| 75 × 8 mm | 4.710 kg | 28.26 kg |
| 75 × 10 mm | 5.887 kg | 35.32 kg |
| 100 × 10 mm | 7.850 kg | 47.10 kg |
| 100 × 12 mm | 9.420 kg | 56.52 kg |
MS Flat Quality & Documentation
On an MS Flat order, quality comes down to the specification and the paperwork agreeing with each other.
Product Specification
Confirm that what arrives is the product described in your order, and that markings and packing correspond to the consignment documentation.
Grade & Size
Grade and size are confirmed against your requirement, so check them against the order rather than assuming. Measure width, thickness and length on a sample basis at receipt.
Material Documentation
Keep the documentation supplied with the consignment in your project records. Available documentation can be requested at the time of enquiry.
Related Steel Products
MS Flats are supplied alongside the rest of our mild steel product range — round bars, square bars, angles, channels and beams.
Solid round steel bars for fabrication, machining and general engineering work.
Solid square steel bars for fabrication, grills and general engineering work.
L-shaped mild steel sections for frames, supports and fabrication.
C-section steel for structural framing and load-bearing applications.
I-section steel for structural framework and building construction.
MS Flat Questions, Answered
Common questions on MS Flat sizes, grades and ordering. Not covered here? Reach us on WhatsApp or at sales@raipursteelmart.com.
What are MS Flats used for?
What is the difference between a flat and a plate?
How is flat weight calculated?
How can I request a quotation for MS Flats?
Do you supply MS Flats in bulk?
Request an MS Flat Quote
Tell us the size, grade, quantity and delivery location. We will come back with what can be arranged and the next step.
